RASPBERRY-PI  RASPBERRY-MODA-256M  256MB Raspberry Pi Model A Board

Technical Data Sheet (379.11KB) EN Bekijk alle technische documenten

De afbeelding is alleen ter illustratie. Zie de productbeschrijving.

RASPBERRY-PI RASPBERRY-MODA-256M
RASPBERRY-PI RASPBERRY-MODA-256M
RASPBERRY-PI RASPBERRY-MODA-256M
RASPBERRY-PI RASPBERRY-MODA-256M
RASPBERRY-PI RASPBERRY-MODA-256M
RASPBERRY-PI RASPBERRY-MODA-256M
RASPBERRY-PI RASPBERRY-MODA-256M
360°

Productoverzicht

RASPBERRY-MODA-256M is an ultra low cost, deck of cards sized Linux computer. The Model A Raspberry Pi is a stripped down version of the Model B Raspberry Pi, with no Ethernet, one USB port and 256MB RAM. The trade off for removing certain features results in the Model A Raspberry Pi being cheaper than the Model B in addition to using only one third the power. This low power consumption makes it ideal for projects running from a battery or solar power robots, sensor platforms in remote locations and WiFi repeaters for example. Developed by the Raspberry Pi Foundation in the UK, the Raspberry Pi aims to put the fun back into learning computing by promoting the study of computer science and programming at a school level.
  • Model A Raspberry Pi with mounting points and 256MB RAM
  • Broadcom BCM2835 ARM11 700MHz SoC processor (Similar performance to 300MHz Pentium 2 processor)
  • Integrated videocore 4 GPU capable of playing full 1080p high definition Blu-Ray quality video
  • Free, versatile, and highly developer friendly Debian GNU/Linux operating system
  • USB ports
  • HDMI and RCA video output
  • 3.5mm audio output jack
  • 5V micro USB power input jack
  • SD, MMC, SDIO flash memory card slot
  • 26 pin 2.54mm header expansion slot

Productgegevens

Silicon Manufacturer:
Broadcom
Core Architecture:
ARM
Core Sub-Architecture:
ARM11
Silicon Core Number:
BCM2835
Silicon Family Name:
BCM2xxx
Kit Contents:
Eval Board BCM2835
Product Range:
-
No. of Bits:
32bit
Features:
256Mb RAM, ARM1176JZF-S 700 MHz MPU, VideoCore IV GPU, 1 USB, HDMI, mounting holes
SVHC:
To Be Advised

Zoeken naar vergelijkbare producten  per overeenkomende kenmerken

Toepassingen

  • Hobby & Education

Wetgeving en milieu

Land van oorsprong:
Great Britain

Land waarin het laatste noemenswaardige fabricageproces is uitgevoerd

RoHS-compliantie:
Ja
Tariefnummer:
84714900
Gewicht (kg):
.042
