00330-9

00330-9 is a PCIEcan 1xCAN v3 board. This is a small, yet advanced, real time CAN interface that handles transmission and reception of standard and extended CAN messages on the bus with a high timestamp precision. The Kvaser PCIEcan 1xCAN v3 is compatible with applications that use Kvaser‘s CANlib.

• Quick and easy plug-and-play installation and compliant with PCI 2.3
• High-speed ISO 11898 compliant driver circuits, board fits in 3.3V PCI-X, and 3.3V and 5V PCI busses
• I/O mapped for quick reaction times, compatible with our PCIcan boards
• SJA1000 CAN controllers from Philips, with 64-byte receive FIFO
• Supports CAN 2.0 A and 2.0 B (active), 16MHz CAN oscillator frequency
• Galvanic isolation between the CAN controller and the CAN-driver
• Interfaces the CAN bus with D-SUB CAN connectors
• D-SUB 25 connectors, error counters reading, galvanic isolation
• 14000mps messages per second receive, 18000mps messages per second sending
• Linux, Windows operating systems and temperature range from -40 to +85°C
